Overview
| VaproSmart ICL is an "intelligent" interior vapor control layer and air barrier sheet membrane. It dynamically adjusts its vapor permeance in response to surrounding humidity levels, remaining vapor-tight when conditions are dry, and opening up to allow inward vapor diffusive drying when humidity is high, helping to protect the structure from moisture accumulation. VaproSmart ICL is design for use in commercial and residential internal applications. |  |
Why Use VaproSmart ICL
| Smart Vapor Control - adapts permeance to varying humidity in the wall cavity throughout the year to keep the cavity dry. | Improves Energy Efficiency - reduces air and moisture movement, helping to maintain thermal insulation performance and preventing heat loss/gain, contributing to lower energy consumption |
| Mitigates Mold and Mildew - controls air and moisture, mitigating mold and mildew growth that occurs when moisture is trapped especially in walls, ceiling, and floors. | Protects Structural Building Integrity - mitigates moisture damage to essential building components including roofs, walls, and floors, especially in heating climates. |
Technical Data
| PHYSICAL PROPERTIES | |
|---|---|
| PROPERTY | RESULT |
| Color | Translucent |
| Thickness | 0.1767 mm (6.955 mil) |
| 9'8" Roll Dimensions | 9'8" x 98' (3m x 30m) 968 ft² (90 m²) |
| 59" Roll Dimensions | 59" x 98' (1.5m x 30m) 484 ft² (45 m²) |
| Variable Vapor Permeance (EN 12572) | 0.18-17 perms |
| Warranty | 20 year warranty |
